KNB-S/D Series Pin-Type Nano Sand Mill

Can use 0.1-0.2mm grinding beads, suitable for ultra-fine grinding above 70nm.
The design of the rod pin and rotor uses fuid mechanics + simulation technoogy. The distance between the rotor rod pin and the grinding barrel is 7-13mm, with high grinding efficiency and narrow particle size distribution.
The large-area screen adopts a separation system wth a wide outer and narrow inner structure, which has a large flow rate and does not block the machine.
The cooling system is designed according to the spiral stereo thermal principle and fuid principle, which can quickly cool the material and effectively control the grinding temperature.
Imported sealing technology. safe and reliable, adding the same type of solvent as the material to prevent material loss due to leakage.
Pressure, temperature, and liquid level automatic protection devices are interlocked, which is safer to use.
Multiple materials are available for internal structure to meet diferent material requirements.
Optional button operation (explosion-proof) or PLC touchscreen operation.

Hotline

+86-13790585271

Style

KNB-S-0.3L

KNB-S-0.5L/1/2L

KNB-S-3/6/10L

KNB-S-30/60/400L

KNB-S-1000L

parameter
index
application

Model	Effective Volume(L)	Main Motor Power(kw)	Minimum Feeding Volume(L)	Medium Size(mm)	Cooling Water(m³/H)	Overall Dimensions(mm)	Machine Weight(kg)
KNB-S-0.3L	0.3	3	0.5	0.1-2.0	0.2-0.3	500x560x540	50
KNB-S/D-0.5L	0.5	4	2	0.1-2.0	0.4-0.5	1020x780x840	120
KNB-S/D-1L	1	5.5	2.5	0.1-2.0	0.4-0.5	1020x780x840	140
KNB-S/D-2L	2	7.5	5	0.1-2.0	0.6-0.8	1020x780x840	150
KNB-S/D-3L	3	11	20	0.1-2.0	0.8-1	1000x900x1550	400
KNB-S/D-6L	6	15/18.5	30	0.1-2.0	1-1.2	1160x900x1550	500
KNB-S/D-10L	10	22	30	0.1-2.0	1.5-2	1250x900x1750	1280
KNB-S/D-30L	30	37/45	60	0.1-2.0	3-4	1650x1050x1550	1800
KNB-S/D-60L	60	75	100	0.1-2.0	7-8	2230x1050x2200	3480
KNB-S/D-100L	100	110	150	0.1-2.0	10-12	2900x1400x2600	5200
KNB-S/D-150L	150	185	300	0.1-2.0	15-18	2900x1400x2600	6600
KNB-S/D-400L	400	315/355	500	0.1-2.0	30-36	3000x1600x2850	12500
KNB-S/D-1000L	1000	650	1500	0.1-2.0	60-70	5480x2150x2800	20000

Feed particle size: <200 μm
Final particle size: ≥0.06 μm
Solvent type: water-based, solvent-based
Viscosity requirement: <8000CPS
Media size: 0.1-2.0mm
Optional materials: zirconium oxide, silicon carbide, silicon nitride, alloy,polyurethane, polymer, etc.

Battery positive electrode materials, negative electrode materials, conductive slury, diaphragm slury, industrial ceramics (alumina, zirconiun oxide and other oxides, slicon carbide, boron carbide and other carbides, zirconium sicate, slicon nitride and other nitides), nano polishing liquid (alumina, zirconium oxide, cerium oxide, Silicon carbide, diamond, etc.), graphite, graphene, nano new materals, electronic ceramics，nano color pigment, coatings, inks, inkjet inks, medicines, pesticides, magnetic materials,calcium carbonate.
