KJZ Series High-Pressure Homogenizer

Enhanced production stability.
Power system design, long plunger stroke, low-frequency operation.
Adopt four-level safety protection.
Ultra-high pressure and heavy-load power design.
Over pressure protection, overload protection, pressure relief valve, locking fastening components, four-fold safety.
guarantee. SS2205 Ultra-high strength pressure module.

+86-13790585271

Style

Experimental type

Production type

parameter
index
application

Test model table

Model	Flow Rate(H)	Design Pressure(bar)	Motor Power(kw)	Minimum Processing Volume(ml)
KJZ-NANO	10L	2000	1.5	15
KJZ-1500	10-15	1500	2.2	25
BSSIC30	20-30L	1200	2.2	50
KJZ-2020	20-30L	1000	1.5	50
KJZ-PILOT16	30-40L	1800	5.5	60

Pilot Production Model Table

Model	Flow Rate(H)	Design Pressure(bar)	Motor Power(kw)
KJZ-PILOT16	50-60L	1000	5.5
KJZ-PILOT22	80L	600	5.5
KJZ08-100PLUS	80-100L	1500	7.5
KJZ12-150	120-150L	1500	11
KJZ12-300L	260-300L	1000	11
KJZ22-150L	250L	1500	18.5
KJZ15-400L	400L	1000	15

Mass Production Model

Model	Flow Rate(H)	Design Pressure(bar)	Motor Power(kw)
KJZ22-100	500-600L	1000	18.5
KJZ30-150	500L	1500	30
KJZ30-100	800-1000L	1000	30
KJZ37-150	800-1000L	1500	37
KJZ55-100	1800-2000L	1000	55

Biomedicine, chemical industry, yeast extraction, food industry, graphite, graphene, color paste, alumina, etc.
